WeSigma SI-V2 Security Barrier
Features:
90W turbine worm transmission deceleration induction motor, saving energy, motor with fan, prevent overheating, could working 24 hours without stop: Drive Steady, Noise Lower,
Structures Compact, can realize self-locking.
Use 2 springs, the spring is not easy to fracture.
Integrative machine core: all parts are made by mold, so all parts can be more accurate. and so, the barrier gate can be much more stable.
Accurate link mechanism: link mechanism can release arm shake and motor load, so the barrier gate can move more stable and the barrier gate working life can be longer.
Share :
- Category
- Product SKU
Description
Key Specifications:
- Opening and Closing Times: 2s/3s/6s
- Voltage: 220V
- Frequency: 50Hz
- Maximum Remote-Control Distance: ≤40m
- Motor power consumption: 90W
- Drive: Torque motor
- Working temperature: -30° to 80°C
- Housing dimension: 355(Width)*249(Depth)*1035(Height)mm
- Weight not including barrier boom: 50kgs
SIGMA Gate Barrier System
Features:
- Motor: 90W turbine worm transmission deceleration induction motor, saving energy, with fan to prevent overheating, capable of 24-hour continuous operation. Drive is steady, noise is lower, structure is compact, and self-locking is possible.
- Springs: Uses 2 springs, making them less prone to fracture.
- Integrative Machine Core: All parts are made by mold, ensuring accuracy and stability of the barrier gate.
- Accurate Link Mechanism: Releases arm shake and motor load, resulting in more stable movement and longer barrier gate life.
Direction and Boom Types:
| Type | Opening and Closing Times | Maximum Boom Length |
|---|---|---|
| Straight Boom | 2s, 3s, 6s | 3m, 4.5m, 6m |
| Folding Boom | 3s, 6s | 4m, 6m |
Overall, the SIGMA Gate Barrier System offers a reliable and efficient solution for controlling access and traffic flow.
Parameters:
Maximum straight boom length
| 2s type | 3 m |
| 3s type | 4.5 m |
| 6s type | 6m |
Opening and closing times: 2s/3s/6s
Voltage: 220V
Frequency: 50HZ
Motor power consumption: 90W
Working temperature: -30°to 80°
Housing dimension: 355(Width)*249(Depth)*1035(Height)mm
Weight not including barrier boom: 50kgs
Drive: Torque motor
Maximum Remote-Control Distance: ≤40m
Retractable Straight Boom, easy for transportation (Optional):
A = Master Boom, B=Slave Boom
B<=A
Part B can be contracted inside part A. This boom design
is served for easy transportation. From now on, 6m boom
transportation can be easier and more convenient. 6m
A straight boom can be made as 4m+2m or 3m+3m.
