X Rays Sigma Si-7788 Baggage Scanner Security Inspection

Applications

The Sigma Si-7788 X-Ray Baggage Scanner can be used for security screening in:

• Airports and aviation security checkpoints
• Railway and bus transportation terminals
• Government buildings
• Courts and administrative facilities
• Correctional and detention facilities
• Hotels and commercial buildings
• Event and stadium entrances
• Corporate offices
• Customs and border-control facilities
• Warehouses and logistics facilities
• High-security industrial sites

Key Features

• Advanced X-Ray Baggage Inspection
• 500 × 300 mm Inspection Tunnel
• 100 kV X-Ray Generator
• Dual-Energy Material Detection
• 4096-Level Grayscale Imaging
• 64X Smart Image Zoom
• High & Super Penetration Modes
• Organic/Inorganic Material Identification
• 19-Inch Color LCD Display
• 100,000+ Image Storage Capacity
• Liquid & High-Density Material Alarm
• Audio & Visual Security Alerts
• USB Image Export
• Real-Time Image Enhancement
• System Diagnostics & Image Management
• Optional UPS Backup Power
• Wide -20°C to +60°C Operating Range

Product Description

The Sigma Si-7788 X-Ray Baggage Scanner is an advanced security inspection system designed for reliable, efficient, and detailed screening of baggage, luggage, parcels, packages, and other items that require security inspection. Developed for environments where safety and accurate inspection are essential, the Sigma Si-7788 X-Ray Baggage Scanner uses professional X-ray imaging technology to provide operators with a clear view of the internal contents of inspected objects without requiring them to open every bag manually. The system combines X-ray imaging, dual-energy detection, image enhancement, material identification, smart zoom, image storage, and alarm functions to provide a comprehensive security screening solution. The Sigma Si-7788 X-Ray Baggage Scanner can be used in airports, transportation terminals, government buildings, commercial facilities, hotels, correctional institutions, warehouses, logistics centers, event venues, customs areas, and other locations where baggage and package inspection is required.

The Sigma Si-7788 X-Ray Baggage Scanner is designed to improve the speed and effectiveness of security screening by allowing security operators to examine the contents of luggage and packages through X-ray images. Instead of physically opening every item, operators can place baggage on the conveyor system and allow it to pass through the inspection tunnel. The X-ray system generates an internal image that can then be reviewed on the scanner’s display. This process can reduce manual inspection requirements and help security personnel focus their attention on objects or areas that appear suspicious. The Sigma Si-7788 X-Ray Baggage Scanner therefore provides a practical solution for organizations that need continuous and organized security inspection at controlled entry points.

One of the important features of the Sigma Si-7788 X-Ray Baggage Scanner is its 500 × 300 mm inspection tunnel. This tunnel size provides suitable space for inspecting many common types of bags, suitcases, parcels, packages, and other security-sensitive items. The scanner is designed to support smooth movement of baggage through the inspection area while allowing the operator to monitor the resulting X-ray image. Its professional construction makes the Sigma Si-7788 X-Ray Baggage Scanner suitable for locations where reliable inspection equipment is required for regular security operations. Depending on the installation environment, optional entrance and exit rollers can also be used to improve baggage handling and make the overall inspection process more convenient for security staff.

The Sigma Si-7788 X-Ray Baggage Scanner incorporates a 100 kV X-ray generator designed to provide effective internal imaging of inspected objects. When baggage passes through the scanning tunnel, X-rays penetrate the contents and are captured by the detector system. The resulting information is processed and displayed as an inspection image. This allows operators to examine the internal arrangement of objects inside bags and packages without physically opening them. The Sigma Si-7788 X-Ray Baggage Scanner is therefore particularly useful in security environments where fast preliminary inspection is necessary and where manual baggage opening could slow down the screening process.

The X-ray system of the Sigma Si-7788 X-Ray Baggage Scanner is supported by an L-type photo-diode dual-energy detector. Dual-energy detection provides additional information that can assist security operators in differentiating materials within scanned objects. The system can support organic and inorganic material identification, helping operators analyze the contents of baggage more effectively. This capability is particularly valuable when several objects overlap within a bag or when an item is difficult to identify using a basic X-ray image. By providing additional material-related information, the Sigma Si-7788 X-Ray Baggage Scanner helps security personnel perform a more detailed visual examination of scanned items.

Image quality and image processing are important considerations in professional baggage inspection, and the Sigma Si-7788 X-Ray Baggage Scanner provides several functions designed to improve image analysis. The scanner supports different penetration and image-processing modes, including low penetration, high penetration, and super penetration. These functions allow operators to adjust the image according to the density and composition of the inspected baggage. When an object is hidden behind dense materials or multiple items overlap, an appropriate image-processing mode can help improve visibility. The Sigma Si-7788 X-Ray Baggage Scanner therefore gives operators greater flexibility when examining complex baggage contents.

Another useful feature of the Sigma Si-7788 X-Ray Baggage Scanner is its 64X smart image zoom capability. Security personnel can enlarge selected areas of an X-ray image to examine small or unclear objects in greater detail. This can be helpful when an operator notices an unusual shape, dense object, electronic component, container, or other item that requires closer examination. Rather than relying only on the original image size, the operator can use the zoom function to focus on specific areas. The Sigma Si-7788 X-Ray Baggage Scanner combines this smart zoom capability with image enhancement functions to support detailed inspection and more efficient decision-making at security checkpoints.

The Sigma Si-7788 X-Ray Baggage Scanner also provides 4096-level grayscale imaging and four-color imaging functionality. These imaging capabilities allow security operators to view scanned objects with different levels of visual information. Grayscale imaging can provide detailed representation of X-ray density, while color imaging can assist with material differentiation and visual interpretation. The combination of these imaging functions gives the Sigma Si-7788 X-Ray Baggage Scanner a flexible inspection interface for examining different types of baggage and packages.

For operator convenience, the Sigma Si-7788 X-Ray Baggage Scanner is equipped with a 19-inch color LCD monitor with a 1280 × 1024 resolution. The monitor provides a dedicated display area for viewing X-ray images and using available inspection functions. During normal operation, the security operator can monitor baggage as it passes through the tunnel and immediately review the resulting image. The clear display helps operators examine the shape, density, and arrangement of objects inside baggage. The Sigma Si-7788 X-Ray Baggage Scanner is designed to make image inspection practical for security personnel who may need to work continuously for extended periods.

The system also includes audio and visual indication functions for liquids and high-density substances. These alarm functions can help draw the operator’s attention to areas that may require additional examination. When the Sigma Si-7788 X-Ray Baggage Scanner identifies conditions associated with liquids or high-density materials, the corresponding indication can provide an additional point of attention for the security operator. The operator can then use image enhancement, zoom, penetration modes, and material identification functions to examine the relevant area more closely. These combined capabilities make the Sigma Si-7788 X-Ray Baggage Scanner a useful tool for security teams that require multiple inspection functions within one system.

Image storage is another important capability of the Sigma Si-7788 X-Ray Baggage Scanner. The system supports storage of more than 100,000 images, providing organizations with significant capacity for maintaining inspection records. Stored images can be useful for reviewing previous scans, operator training, security analysis, quality control, and documentation. The ability to store a large number of images can also help organizations maintain a reference library for training new security personnel. The Sigma Si-7788 X-Ray Baggage Scanner therefore provides functionality beyond real-time inspection by supporting image management and review after the scanning process.

The image-management functions of the Sigma Si-7788 X-Ray Baggage Scanner can include image review, time and date information, system logs, counting functions, and system diagnostics. These features can help security teams monitor scanning operations and manage inspection information. Security personnel can review stored images when necessary and use available system information to support equipment management. The Sigma Si-7788 X-Ray Baggage Scanner also supports USB image output, providing a practical way to export selected images when required for documentation, analysis, training, or other authorized purposes.

The Sigma Si-7788 X-Ray Baggage Scanner is designed for practical security screening in environments where baggage inspection needs to be organized and efficient. At airports, the scanner can be positioned at controlled security checkpoints to inspect passenger luggage and other items. In transportation terminals, it can be used for screening baggage and parcels before passengers enter restricted areas. Government offices and administrative buildings can use the Sigma Si-7788 X-Ray Baggage Scanner to inspect bags at entrances and security checkpoints. Similarly, commercial buildings, hotels, event venues, and corporate facilities can deploy the system to provide an additional layer of security.

In correctional facilities and other controlled environments, the Sigma Si-7788 X-Ray Baggage Scanner can assist security personnel with the inspection of bags and packages entering restricted areas. The ability to view the internal contents of a package without immediately opening it can help streamline the initial screening process. Security operators can identify objects that appear unusual or require further investigation and then follow the facility’s established inspection procedures. The Sigma Si-7788 X-Ray Baggage Scanner can therefore support controlled-access environments where security inspection is a regular operational requirement.

The scanner is also suitable for selected warehouse, logistics, customs, and industrial applications. Packages can be inspected before entering restricted zones or being transferred into sensitive areas. The Sigma Si-7788 X-Ray Baggage Scanner can provide security personnel with an X-ray image that helps them assess package contents without relying solely on external packaging. This can be particularly useful in locations where numerous packages or parcels need to be processed and where maintaining an efficient inspection workflow is important.

The physical construction of the Sigma Si-7788 X-Ray Baggage Scanner is designed for professional security environments. The system has approximate dimensions of 2360 × 720 × 1193 mm and a net weight of approximately 280 kg. Its robust structure provides stability during regular operation. The scanner can be installed as part of a dedicated security checkpoint, with the conveyor and optional rollers arranged according to the available site space and workflow requirements. The overall design provides a balance between inspection functionality and practical installation for professional security applications.

The Sigma Si-7788 X-Ray Baggage Scanner is designed to operate across a broad temperature range of approximately -20°C to +60°C. This makes the equipment suitable for various indoor operating environments where temperature conditions may change. The specified storage temperature range is approximately -30°C to +70°C, while the supported humidity range is approximately 5% to 95% non-condensing. These environmental specifications provide organizations with useful information when planning the installation and operating conditions for the scanner.

Power requirements are also an important consideration when installing an X-ray inspection system. The Sigma Si-7788 X-Ray Baggage Scanner supports a power supply of approximately 110–240 VAC with a frequency of 50/60 ± 3 Hz. The listed power consumption is less than approximately 0.5 kW/h. Organizations should ensure that the installation location provides a suitable electrical supply and follows applicable safety and installation requirements. Proper installation and regular maintenance can help ensure that the Sigma Si-7788 X-Ray Baggage Scanner performs reliably during routine security screening operations.

For locations where power continuity is important, the Sigma Si-7788 X-Ray Baggage Scanner can be configured with an optional UPS backup system. The listed optional UPS can provide up to approximately 30 minutes of backup operation, depending on the configuration and operating conditions. Backup power can help reduce interruptions caused by temporary power failures and provide security personnel with additional time to manage the inspection process safely. This option can be particularly useful in security facilities where maintaining operational continuity is an important requirement.

Optional accessories can further expand the installation possibilities of the Sigma Si-7788 X-Ray Baggage Scanner. Smart rollers can be used to assist baggage movement, while optional two-direction scanning configurations may provide additional flexibility for certain inspection layouts. Stainless-steel entrance and exit rollers are also available as an optional configuration. These accessories can help organizations customize the scanner according to the physical layout and workflow of their security checkpoint. The exact configuration can be selected according to the requirements of the installation site.

The Sigma Si-7788 X-Ray Baggage Scanner is also designed with operator-focused functions that help simplify the inspection process. Security personnel can monitor the conveyor, view X-ray images, apply image enhancement functions, zoom into specific areas, and use material identification features during inspection. This combination of functions allows operators to adapt the viewing method according to the contents of each bag. The Sigma Si-7788 X-Ray Baggage Scanner is therefore suitable for professional security teams that require a flexible and comprehensive inspection interface.

An important advantage of the Sigma Si-7788 X-Ray Baggage Scanner is its ability to provide non-invasive inspection of baggage. Security personnel can examine the internal contents of luggage without immediately opening the bag. This can make the initial screening process faster and can help reduce unnecessary manual handling. When an image indicates an object that requires additional attention, security personnel can follow the appropriate secondary inspection procedures. In this way, the Sigma Si-7788 X-Ray Baggage Scanner can support a layered security screening approach.

The material differentiation capability of the Sigma Si-7788 X-Ray Baggage Scanner is particularly useful when inspecting baggage containing many different objects. Bags may contain clothing, electronics, containers, tools, personal belongings, and other items that overlap in the X-ray image. Dual-energy imaging and available organic/inorganic identification functions can provide additional information for interpreting these images. Combined with smart zoom and penetration modes, these functions help operators analyze complex images more effectively.

The Sigma Si-7788 X-Ray Baggage Scanner can also support security operator training. The large image storage capacity allows authorized personnel to maintain examples of different X-ray images for educational and operational purposes. Training teams can use stored images to help operators become familiar with different shapes, densities, materials, and image patterns. This can contribute to more consistent inspection performance when the scanner is deployed in a busy security environment.

Maintenance and system monitoring are also important aspects of long-term operation. The Sigma Si-7788 X-Ray Baggage Scanner provides system diagnostic functions that can assist authorized personnel in monitoring equipment status. Organizations should follow the manufacturer’s recommended maintenance procedures and applicable safety requirements for X-ray equipment. Regular inspection, cleaning, servicing, and appropriate operator training can help maintain reliable operation and support the long-term performance of the Sigma Si-7788 X-Ray Baggage Scanner.

Available at atozsecurityequipment in Dubai and kigalismartsolutions in Rwanda

Product Brochure: Sigma Si-7788 Baggage Scanner
